Scanner Laser Doppler Vibrometer (LDV) – LS01 OMS Scanning Laser Doppler Vibrometer
| Specification | Details |
|---|---|
| Application | Industrial |
| Model | LS01 |
| Country of Origin | Made in India |
| Velocity Range | 5 mm/s to 800 mm/s |
| Vibration Frequency Range | 0.1 Hz to 20 kHz |
| Working Distance | 0.5 m to 5 m |
| Optics | Collimated (No Focusing Needed) |
| Signal Output | Analog Velocity and 10.7 MHz FM Outputs |
| Laser Head Dimensions | 36 x 25 x 18 cm |
| Electronic Controller Dimension | 43 x 33 x 10 cm |
| Laser Head Weight | 10 Kg |
| Electronic Controller Weight | 6.2 Kg |
- Description
- Reviews (0)
Description
LS01 OMS Laser Scanning Vibrometer
The LS01 Laser Scanning Vibrometer is a non-contact vibration measurement system designed for precise and high-frequency vibration analysis in industrial environments. Ideal for structural testing, quality control, and dynamic behavior diagnostics, the LS01 provides reliable, real-time measurement of velocity across a wide frequency range without interfering with the target surface.
Key Features
- Non-contact operation eliminates mass-loading effects
- Wide working distance (up to 5 meters), ideal for hard-to-reach or hazardous zones
- Broad frequency response up to 20 kHz for dynamic and structural monitoring
- Dual outputs: Analog velocity and FM for flexible data acquisition
- Simple alignment with collimated laser optics (no manual focusing required)
Typical Applications
- Modal and structural analysis
- Aerospace, automotive & mechanical component testing
- Condition monitoring in rotating machinery
- Laboratory and industrial R&D environments
