Vibration Sensor – General Purpose Accelerometer With 4-20ma Output MTN/2285-2P Series
| Specification | Details |
|---|---|
| Output current | 4-20mA DC proportional to rms velocity (mm/s) |
| Supply voltage range | 12-32V DC (4-20mA) |
| Frequency response | 2Hz to 1kHz ±10% |
| Mounted base resonance | 5kHz (nominal) |
| Isolation | Electronics in Faraday cage, isolated from body |
| Dynamic range | 50g peak |
| Transverse sensitivity | Less than 5% |
| Operating temperature | -25 to 90 °C |
| Temperature sensitivity | 0.08%/°C |
| Case material | Stainless steel |
| Mating connector | MTN/MH002 |
| Mounting torque | 8Nm |
| Weight | 140g (nominal) |
| Sealing | IP67 |
- Description
- Reviews (0)
Description
Vibration Sensor – MTN/2285-2P Series
The MTN/2285-2P Series is a robust, general-purpose vibration sensor designed for industrial condition monitoring applications. It provides a reliable 4–20mA current loop output, proportional to rms velocity (mm/s), making it ideal for integration into PLCs, SCADA systems, and data loggers.
Key Features
- Standard 4–20mA Output: Output current is directly proportional to the vibration velocity, enabling real-time condition monitoring.
- Wide Operating Range: Covers a frequency response of 2Hz to 1kHz ±10%, suitable for most rotating equipment.
- High Dynamic Range: Withstands up to 50g peak, ideal for industrial environments with variable loads and speeds.
- Durable Construction: Stainless steel housing, IP67 sealing, and internal electronics housed in a Faraday cage ensure long-term stability and electrical isolation.
- Excellent Environmental Resistance: Operates reliably in temperatures from −25°C to +90°C and harsh industrial conditions.
Ideal For
- Motors, pumps, fans, and gearboxes
- Industrial automation and maintenance programs
- Continuous vibration monitoring systems
