Vibration Sensor Calibration Equipment – GJX-5i Vibration Calibrator Shaker Table
| Parameter | Details |
|---|---|
| Frequency | Fixed: 10, 20, 40, 80, 160, 320, 640, 1280 Hz External input: any signal with continuous frequency adjustment, sweep, non-sine wave |
| Amplitude Accuracy | Acceleration (@30 m/s² pk) 40–320 Hz: ±0.3 dB ±1 digit 20–1280 Hz: ±0.5 dB ±1 digitVelocity (@25 mm/s pk) 40–320 Hz: ±0.5 dB ±1 digitDisplacement (@50 µm pk-pk) 40–320 Hz: ±0.5 dB ±1 digit |
| Proximity Probe Linearity | Probe: 5 mm and 8 mm Range: 0 – 2.0 mm |
| Display | 3½-digit display for acceleration, velocity, or displacement |
| Size | 280 × 180 × 250 mm |
| Gross Weight | 10 kg |
| Temperature (Operation) | 0°C to 50°C |
| Temperature (Storage) | −20°C to 70°C |
| Power Supply | 220Vac (optional 110Vac) |
- Description
- Reviews (0)
Description
Product Overview: GJX-5i Vibration Calibrator Shaker Table
The GJX-5i Vibration Calibrator is a compact, versatile shaker table system designed to provide accurate calibration of vibration sensors, transducers, and proximity probes. Whether you’re working in a calibration lab, performing on-site testing, or supporting an industrial condition monitoring program, the GJX-5i ensures precise and repeatable verification of your vibration instrumentation.
With a robust frequency range, multi-parameter output (acceleration, velocity, displacement), and compatibility with external input signals, the GJX-5i is an essential tool for maintenance engineers, QA technicians, and metrology professionals.
| Frequency (Hz) | ≤100g a (m/s²) | ≤100g v (mm/s) | ≤100g d (µm) | ≤250g a (m/s²) | ≤250g v (mm/s) | ≤250g d (µm) | ≤650g a (m/s²) | ≤650g v (mm/s) | ≤650g d (µm) |
|---|---|---|---|---|---|---|---|---|---|
| 10 Hz | 2.5 | 28 | 1300 | 3.5 | 40 | 1800 | 4 | 45 | 2000 |
| 20 Hz | 15 | 85 | 1900 | 10 | 60 | 1300 | 5 | 28 | 640 |
| 40 Hz | 60 | 170 | 2000 | 35 | 100 | 1100 | 12 | 35 | 380 |
| 80 Hz | 100 | 141 | 800 | 40 | 60 | 320 | 14 | 20 | 110 |
| 160 Hz | 40 | 53 | 150 | 35 | 25 | 70 | 12 | 8.5 | 24 |
| 320 Hz | 30 | 18 | 25 | 30 | 10 | 15 | 10 | 3.5 | 5 |
| 640 Hz | 30 | 5 | 3 | 20 | 3.5 | 2 | 6 | 1 | * |
| 1280 Hz | 23 | 2 | * | 10 | 0.9 | * | 5 | 0.4 | * |
* indicates not specified.
Key Features
- Wide Frequency Range: Fixed outputs at 10, 20, 40, 80, 160, 320, 640, and 1280 Hz; supports external signals including sweeps and non-sine waves
- Multi-Parameter Calibration: Measures acceleration, velocity, and displacement with high accuracy across 40–320 Hz and extended up to 1280 Hz
- Proximity Probe Support: Compatible with 5 mm and 8 mm probes; linearity testing range from 0 to 2.0 mm
- User-Friendly Display: 3½-digit display for real-time monitoring of all output parameters
- Compact & Portable: Space-efficient design (280 × 180 × 250 mm), weighs just 10 kg — ideal for lab or field use
- Durable in Harsh Conditions: Operates from 0°C to 50°C; storage range from −20°C to 70°C
- Flexible Power Options: Standard 220V AC input with optional 110V AC version available
Applications
- Calibration of piezoelectric accelerometers, velocity sensors, and displacement probes
- On-site validation of vibration monitoring systems
- Maintenance of sensors used in turbines, motors, pumps, and rotating equipment
- Verification of proximity probe linearity for shaft monitoring systems
- Essential for QA labs and ISO 17025 accredited calibration facilities
Why Choose iAdept Marketing?
As experts in condition monitoring and sensor diagnostics, iAdept Marketing provides reliable calibration solutions for critical industries. When you work with us, you benefit from:
- Industry Expertise: Decades of experience supporting predictive maintenance and sensor diagnostics
- Technical Support: Setup assistance, training, and post-sale support for all calibration equipment
- Quality Equipment: Trusted, field-proven tools that meet international standards
- Prompt Service: Fast deliveries and responsive service across India
The GJX-5i Vibration Calibrator is your go-to solution for precise, repeatable, and flexible sensor calibration. Contact iAdept Marketing today to schedule a demo or request a technical datasheet.
