Vibration Meter Pen Type Bearing Damage Detector TPI 9070
| Specification | Details |
|---|---|
| Size | H 7.95” W 2.36” |
| Weight | 9.8oz (280g) |
| Environmental | Water: IP67 Waterproof Operating: 32°F to 122°F (0°C to 50°C) Storage: -4°F to 158°F (-20°C to 70°C) |
| Power supply | 2xAA batteries |
| Battery life | Approximately 50 hours of normal use |
| Frequency ranges | 2/10Hz – 1kHz ISO 2Hz – 3kHz |
| Frequency resolution | 100 / 200 / 400 / 800 lines |
| Displayed amplitude units | Acceleration in g / velocity in inches per second or mm per second / Bearing damage in BDU |
| Displayed frequency units | Hz, CPM or RPM |
| Input range | +/- 50 g |
| Dynamic range | 72 dB |
| Auto set up of VA bands | Yes |
| Accelerometer connection | Internal sensor |
| Standard accessories | Pouch with protective cap for pointed stinger |
| Optional accessories | Magnet |
- Description
- Reviews (0)
Description
TPI 9070 – Pen-Type Vibration Meter & Bearing Damage Detector
The TPI 9070 is a lightweight, pen-style vibration meter designed for quick and reliable checks of machine condition. It combines simplicity with advanced measurement capabilities, making it an essential tool for maintenance engineers monitoring bearing wear, imbalance, misalignment, and other common faults.
Key Features
- Integrated Sensor – No external cables or accelerometers required
- Compact Pen-Style Design – Ideal for pocket use in plant environments
- Bearing Damage Detection – Displays in BDU (Bearing Damage Units)
- Auto Band Setup – Simplifies vibration analysis for non-experts
- Waterproof (IP67 Rated) – Rugged and ready for industrial use
Included Accessories
- Pouch with protective cap
- Pointed stinger for contact measurements
Optional Accessory
-
Magnetic mounting adapter
Ideal For
- Routine bearing checks
- Quick machine condition verification
- Portable route-based inspections
- First-line maintenance teams
