Vibration Analyzer – 701TXV Vibration Data Collector
| Feature / Parameter | 4 Channel (9034) | 8 Channel (9038) |
|---|---|---|
| IEPE Accelerometer Input Channels | 4 | 8 |
| Accelerometer Sampling Frequency | 2Hz – 25.6kHz | 2Hz – 25.6kHz |
| 4-20mA Output Channels | 4 | 8 |
| 24VDC Digital Outputs | 4 | 8 |
| 24VDC Digital Output Current Max | 100mA | 100mA |
| Digital Output Alarm | Acceleration or Velocity (Channel Selectable) | Acceleration or Velocity (Channel Selectable) |
| Tachometer Input | 1 (0V to +24VDC) | 1 (0V to +24VDC) |
| Frequency Dependent Alarms | Yes (using Tachometer) | Yes (using Tachometer) |
| Temperature Input | 1 (Typically 10mV/°C) | 1 (Typically 10mV/°C) |
| PC Connection | USB | USB |
| Internet/Cloud Connection | Ethernet | Ethernet |
| Vibration Alarms | 4 | 8 |
| Temperature Alarm | 1 | 1 |
| Alarm Choice | Acceleration AND/OR Velocity (Channel selectable) | Acceleration AND/OR Velocity (Channel selectable) |
| FFT (Spectral Analysis) | Up to 51,200 lines | Up to 51,200 lines |
| Time Waveform | Yes (with PC software) | Yes (with PC software) |
| Supply Voltage | USB or 24VDC | USB or 24VDC |
| Supply Current | 500mA | 500mA |
| Environmental Protection | IP50 | IP50 |
| Operating Temperature | 0–55°C (32–131°F) | 0–55°C (32–131°F) |
| Storage Temperature | 0–55°C (32–131°F) | 0–55°C (32–131°F) |
| Mounting | DIN Rail | DIN Rail |
| Part Number | 9034 | 9038 |
- Description
- Reviews (0)
Description
701TXV Vibration Data Collector & Analyzer
The 701TXV Vibration Data Collector & Analyzer by iAdept Marketing is a portable handheld vibration analyzer designed for a wide range of industrial applications. Built for reliability and ease of use, the 701TXV is ideal for predictive maintenance, machine health monitoring, and field diagnostics. It enables maintenance professionals to quickly measure and analyze vibration levels, helping identify issues such as unbalance, misalignment, or bearing faults before they lead to costly downtime. Its compact design, digital display, and accurate measurement capabilities make it a practical tool for condition monitoring in various industries.
Performance & Measurement Capabilities
- Real-Time Vibration Measurement: Measures vibration in acceleration, velocity, and displacement modes.
- FFT Spectrum Analysis: Detects bearing faults, unbalance, misalignment, looseness, and more using frequency domain analysis.
- Time Waveform Display: Useful for advanced diagnostic analysis in the time domain.
- RMS, Peak, Peak-to-Peak Readings: Essential for condition monitoring and ISO standard compliance.
- Optional Tacho Input: Enables RPM measurement, phase analysis, and machine balancing when equipped.
Applications
- Industrial condition monitoring of: Motors, Pumps, Fans, Compressors, Gearboxes, Conveyors, Blowers
- Maintenance route data collection
- On-site fault analysis
- Factory Acceptance Tests (FAT)
- Trending and predictive maintenance programs
Key Features
- Compact & Ergonomic: Slim design allows for easy one-hand operation in tight industrial environments.
- Accurate Vibration Diagnostics: High sensitivity and precision ensure early fault detection.
- PC Connectivity: Data export via USB or serial connection to analysis software (available optionally).
- Data Logging: Save readings directly to internal memory; supports basic trending (optional PC software).
- Long Battery Life: Supports extended operation during routine maintenance rounds.
Standard Package Includes
- 701TXV Vibration Analyzer
- Carrying case
- Charger/Adapter
- Accelerometer with cable and magnet (optional)
- Calibration certificate (on request)
- User manual
Optional Accessories
- Tachometer sensor (laser or proximity)
- Strobe light (for phase reference)
- Advanced PC software for FFT and trend plotting
- Extended cable sets or mounting adapters
- Ruggedized transport case
Why Choose the 701TXV?
- Designed specifically for maintenance engineers, reliability professionals, and field technicians.
- Combines affordability with powerful diagnostic features.
- Part of iAdept’s trusted lineup for machine fault analysis and condition-based monitoring.
