EyeLink 1000 Plus - Image 1

EyeLink 1000 Plus

EyeLink Portable Duo
Pupil Labs Eye Tracker “NEON”
0 out of 5
( There are no reviews yet. )

Feature Details
System Versions EyeLink 1000 Plus Camera and Workstation or Laptop Host PC
Sampling Rate – Head Supported: 2000 Hz Monocular / 2000 Hz Binocular
– Remote: 1000 Hz Monocular / 1000 Hz Binocular
Accuracy – Head Supported: Down to 0.15° (0.25° – 0.5° typical)
– Remote: 0.25° – 0.5° typical
Resolution – Head Supported: 0.01° RMS / 0.001° Microsaccade resolution
– Remote: 0.05° RMS / 0.25° saccade resolution
Real-Time Data Access – Head Supported: M = 1.4 msec (SD < 0.2 msec) @ 2000 Hz
– Remote: M = 2.4 msec (SD < 0.3 msec) @ 1000 Hz
Data Output X, Y, and Pupil Size
Host PC Workstation or Laptop Host PC
Participant Setup Very simple and easy. Typically less than 2–5 minutes.
Mounting Options Desktop Mount:
– Easy to transport
– Track with head free-to-move or with head supported
– No electronics near participant’s head
– Configurable 32° × 25°
Binocular Tower Mount:
– Fast and easy setup
– Ideal for close-up stimuli, touchscreens and reaching
– 60° × 40° trackable range
LCD Arm Mount:
– Bring the stimulus to the subject
– Ideal for infant tracking or patients in a hospital bed
– Configurable 32° × 25°
Long Range Mount:
– Ideal for MRI or MEG
– 60 – 150 cm eye-to-camera distances
Primate Mount:
– Ideal for non-human primate tracking
– 60° × 40° trackable range
Camera Upgrades Remote (Head Free-to-Move) Upgrade:
– A default Desktop or LCD Arm mount system can be transformed into a Binocular 1000 Hz Remote Head Free-to-Move eye tracker (stabilization not required)
2000Hz Upgrade:
– New EyeLink 1000 Plus systems (from Spring 2017) support 2000 Hz with head stabilization and 1000 Hz without
– Upgrade available for existing systems
Category:
Product Brochure
WhatsApp Now

Description

Product Overview: EyeLink 1000 Plus Eye Tracking System

The EyeLink 1000 Plus is one of the most advanced and high-performance eye-tracking systems available for neuroscience, psychology, and human behavior research. Trusted by leading academic and clinical researchers worldwide, this system offers ultra-high sampling rates, exceptional spatial resolution, and a range of flexible mounting options—making it ideal for everything from infant studies to primate research, touchscreen tasks, and MRI compatibility.

Whether you’re conducting real-time gaze tracking, pupillometry, or oculomotor research, the EyeLink 1000 Plus delivers precision, reliability, and adaptability for the most demanding applications.

Key Features

  • Flexible System Configurations: Use with workstation or laptop host PCs, choose from head-supported or remote (head-free) modes.
  • Industry-Leading Sampling Rates: Head Supported Mode: Up to 2000 Hz, monocular or binocular, Remote Mode: Up to 1000 Hz, monocular or binocular.
  • Outstanding Accuracy: Head Supported: as precise as 0.15° (typical 0.25°–0.5°), Remote Mode: 0.25°–0.5° typical.
  • Exceptional Resolution: Microsaccade-level detection with 0.001° resolution (head supported).
  • Real-Time Data Access: Minimal latency — as low as 1.4 ms at 2000 Hz (head supported), 2.4 ms latency at 1000 Hz (remote mode).
  • Comprehensive Data Output: Tracks X, Y coordinates and pupil size in real time or for post hoc analysis.
  • Quick Setup: Participant preparation takes less than 2–5 minutes, ideal for high-throughput studies.

Mounting Options

  • Desktop Mount: Lightweight, portable, and supports both head-free and head-supported tracking.
  • Binocular Tower Mount: Optimized for touchscreen tasks, close-up stimuli, and precise binocular recording.
  • LCD Arm Mount: Adjustable setup ideal for infant tracking or research with bed-bound patients.
  • Long Range Mount: Designed for MRI/MEG environments, allowing 60–150 cm camera distances.
  • Primate Mount: Specialized for non-human primate tracking with full 60° × 40° field coverage.

Upgrade Options

  • 2000 Hz Upgrade: Enables head-supported systems to sample at 2000 Hz; compatible with new and existing EyeLink 1000 Plus units.
  • Remote Upgrade: Convert a Desktop or LCD Arm mount into a Remote, Head-Free Binocular System running at 1000 Hz — no stabilization required.

Why Choose EyeLink 1000 Plus?

  • Proven Reliability: Used in thousands of peer-reviewed studies
  • Versatility: Multiple mount and camera configurations for virtually any study design
  • Precision Tracking: Microsaccades, fixations, and saccades with unmatched accuracy
  • Low Latency: Critical for real-time feedback and gaze-contingent experiments
  • Flexible Data Access: Real-time gaze data streaming or post-session analysis
  • Trusted Worldwide: Preferred by top universities, research labs, and clinical institutions

EyeLink 1000 Plus is the gold standard in high-speed, high-precision eye tracking. Whether for clinical, behavioral, or cognitive research, it provides unmatched performance and adaptability to meet the most demanding scientific needs.

Contact iAdept Marketing today to learn more, schedule a demo, or request a customized solution for your research environment.
